PHILIPS PMEM1505PG PNP transistor/Schottky recti er module handbook

PMEM1505PG is a PNP transistor/Schottky rectifier module from Philips Semiconductors that combines a low VCEsat and high current capability PNP transistor with a planar Schottky barrier rectifier with an integrated guard ring for stress protection in a SOT353 (SC-88A) small plastic package. It is suitable for DC-to-DC converters, inductive load drivers, general purpose load drivers, reverse polarity protection circuits and MOSFET drivers.

Brand: Philips
File format: PDF
Published: 03 July, 2012
Updated: 30 September, 2023
MD5 checksum: 891C2707028669CF1C6AA5282D0C439B
PDF: PHILIPS PMEM1505PG PNP transistor/Schottky recti er module handbook PDF

Download PDF
