Power-One's MAP110 series of power supplies combines low cost and universal input in a board-only power solution to meet commercial and industrial requirements. Full international safety, EMI, and ESD compliance ensure world-wide acceptance. All units bear the CE Mark. Wide dynamic output current and fixed frequency operation simplifies system level operation. The MAP110 series is configured to an international standard footprint. Input and output connections are made via popular single-row Molex connectors. Single output models feature wide-range output adjustability to meet a wide variety of standard and user specific output voltage requirements.
The Power-One MAP110 series combines low cost and universal input (85-264 VAC) in a board-only power solution designed for commercial and industrial requirements. All units bear the CE Mark and feature full international safety, EMI, and ESD compliance to ensure worldwide acceptance.
The series includes single and multiple output models with wide dynamic output current and fixed frequency operation. Key features include industry-standard footprints, remote sense capabilities, over-voltage protection, and options for over-temperature protection, power fail signals, and chassis covers. The datasheet provides detailed specifications for voltage ranges, output currents, regulation, and environmental limits.
| Input Voltage | 85-264 VAC |
|---|---|
| Input Frequency | 47-63 Hz |
| Industry Standard Footprint | 7.00" x 4.30" x 1.97" |
| MTBF | Greater than 134,000 Hours |
| Operating Temperature | 0 to 50 °C (100% load) |
| Storage Temperature | -55 to 85 °C |
| Agency Approvals | UL1950, CSA 22.2 No. 234/950, EN60950 |
| Dielectric Withstand Voltage | 2600 VDC |
The industry standard footprint is 7.00" x 4.30" x 1.97" (177.8mm x 109.2mm x 50.0mm).
Yes, options include over-temperature protection which initiates a system shutdown due to excessive internal temperature.
The maximum non-operating altitude is 50,000 feet ASL, with an operating limit of 10,000 feet ASL.
