Power-One QBS DC-DC Converter Datasheet

Datasheet 2 pages · 82 KB · EN

The QBS single‑output DC‑DC converters deliver up to 120 W in an open‑frame, quarter‑brick footprint. They feature planar magnetics, high power density, and are suited for telecom, networking, and industrial applications. The series supports both positive and negative enable logic and is water‑washable for manufacturing processes.

The datasheet lists detailed electrical specifications, including input voltage ranges of 18‑36 VDC (24 V nominal) or 36‑75 VDC (48 V nominal), output voltages from 2.5 V to 15 V, 1500 VDC isolation, 30 ms turn‑on time, and efficiencies up to 86 % at full load. Safety approvals, MTBF of 2.5 × 10⁶ h, and thermal limits are also provided.

Covers: Technical Specifications · Model Selection · Mechanical Drawing · Thermal Impedance · Safety Information · Efficiency vs Load

Power-One SLD10 Series 10A Non-Isolated DC/DC Converter Product Brief

Datasheet 2 pages · 46 KB · EN

The SLD10 Series offers two independently regulated low‑voltage outputs from a single 3.3 V or 5 V input. Each output can deliver up to 6 A, with a combined maximum of 10 A, and includes features such as remote ON/OFF control, output voltage trim, and over‑current protection.

Mechanical drawings show straight and right‑angle pin configurations, and the brief lists ordering options, suffixes for part numbers, and notes on usage restrictions and tolerances.

Covers: Features · Description · Specifications · Mechanical Drawing – Dimensions · Pin Function · Ordering Information

Latest Power-One manuals

• Power-One QBS DC-DC Converter Datasheet

  Datasheet 2 pages · 82 KB · EN

  The Power-One QBS DC-DC Converter datasheet provides specifications, performance data, and safety information for the QBS series of converters.

• power-one 120...195 Watt DC-DC Converters handbook

  P Series 120.195 Watt DC-DC Converters have an extremely slim case (4 TE), fully enclosed. Extremely low inrush current, hot swappable. Operating ambient temperature range -40.71°C with convection cooling.

• POWER-ONE Q Series 60...132 Watt DC-DC Converters Manual

  This document describes the features and characteristics of Power-One's Q Series 60.132 Watt DC-DC Converters, including input voltage range, isolated outputs, current and voltage parameters.

• POWER-ONE ZY7010L 7A DC-DC Intelligent POL handbook

  This is a 10A DC-DC intelligent POL data sheet. It is suitable for low-voltage, high-density systems with Intermediate Bus Architectures (IBA). It can be used for high-performance DSP, FPGA, ASIC and microprocessor applications, as well as desktops, servers and portable computing, broadband, networking, optical and communications systems.

• POWER-ONE ZY7120 20A DC-DC Intelligent POL handbook

  The ZY7120 20A DC-DC Intelligent POL Data Sheet 3V to 13.2V Input • 0.5V to 5.5V Output features include: integrates digital power conversion with intelligent power management, eliminates the need for external power management components, completely programmable via industry-standard I2C communication bus, one part that covers all applications, reduces board space, system cost and complexity, and time to market.

• power-one ZY7007 7A DC-DC Intelligent POL Data Sheet 3V to 14V Input 0.5V to 5.5V Output handbook

  This document describes the features and characteristics of the ZY7007 7A DC-DC Intelligent POL. The product has a wide input voltage range, high output current, programmable output voltage range, and various protection functions. It can be widely used in low voltage, high density systems, high performance DSP, FPGA, ASIC, and microprocessor applications.

• POWER-ONE MAP110 SERIES Data Sheet

  Power-One's MAP110 series of power supplies combines low cost and universal input in a board-only power solution to meet commercial and industrial requirements. Full international safety, EMI, and ESD compliance ensure world-wide acceptance. All units bear the CE Mark. Wide dynamic output current and fixed frequency operation simplifies system level operation. The MAP110 series is configured to an international standard footprint. Input and output connections are made via popular single-row Molex connectors. Single output models feature wide-range output adjustability to meet a wide variety of standard and user specific output voltage requirements.

• POWER-ONE HBS SERIES - 75 WATT

  HBS single output DC/DC converters provide up to 75 watts of output power in an industry standard half-brick package and footprint. These units feature excellent efficiency, Class A conducted noise specs, and fixed switching frequency. The HBS features open-frame packaging, along with planar magnetics to provide maximum useable power with minimal thermal constraints. The HBS converters are especially suited to telecom, networking, and industrial applications, and are fully compatible with production board washing processes.

• POWER-ONE PLD08 Series handbook

  The PLD08 series is a surface mount non-isolated DC/DC converter produced by Power-one. It has two independently regulated outputs, efficiency is greater than 90%, output current is up to 8A, load distribution is flexible, output overcurrent protection, remote ON/OFF, and output voltage trim adjustment.

• POWER-ONE 4 - 6W DC/DC Converters handbook

  The NV Series DC/DC converters provide 4-6W output power, suitable for applications such as distributed power architectures, telecommunications equipment, LAN/WAN applications, and data processing.

• POWER-ONE DGP12 SERIES DUAL OUTPUT

  The DGP12 Series dual output power supply provides symmetrical +/– outputs from 5 volts to 15 volts in packages that provide power densities up to 7 watts per cubic inch (0.43 watts per cm3). Designed to operate on ultra-wide input voltages from 3.5 to 16 volts, and with remote ON/OFF capability, the DGP12 supplies power from battery or system sources. The fully isolated, shielded case allows precise operation in sensitive environments.

• POWER-ONE K Series 150 Watt DC-DC Converters

  This product is a 150W DC-DC converter with rugged electrical and mechanical design, fully isolated outputs, operating ambient temperature range of -40.71°C with convection cooling.

• POWER-ONE IMR 25...40 Series 25...40 Watt DC-DC Converters

  IMR 25.40 Series 25.40 Watt DC-DC Converters, input voltage range up to 72 V DC, 1, 2 or 3 outputs up to 30 V DC, 1500 V DC I/O electric strength test voltage

• power-one ZM7300G Series Digital Power Manager Data Sheet

  This data sheet provides detailed information about the ZM7300G series digital power manager, including its applications, benefits, features, and compatibility

• power-one MAP80 SERIES handbook

  Power-One's MAP80 series of power supplies provides reliable, tightly regulated DC power for commercial and industrial systems which require high peak current capabilities. Wide-range AC input and full international safety, EMI, and ESD compliance ensure world-wide acceptance. All units bear the CE Mark. The MAP80 utilizes a variable frequency design with a thermally efficient U-channel chassis to provide full power operation in convection cooled applications. Design innovations include metric and SAE mounting inserts on each mounting surface to provide integration flexibility. Dual-mode connectors provide traditional terminal block connections or popular single row Molex connector mating. Single output models feature wide-range output adjustability to meet a wide variety of standard and user specific output voltage requirements.
