Gemini A is a dual wavelength diffractometer suitable for modern small molecule crystallography laboratories. Designed and brought to you by the world’s leading manufacturers of dual wavelength systems, the Gemini A is a compact and easy-to-use instrument combining the versatility and benefits of co-mounted both molybdenum and copper Enhance X-ray sources on a single 4-circle kappa goniometer.
The Agilent Gemini A is a compact dual wavelength diffractometer designed for small molecule crystallography. It features co-mounted molybdenum and copper Enhance X-ray sources on a single 4-circle kappa goniometer, offering high flux and easy maintenance. The system includes a 135 mm Atlas CCD detector optimized for measuring both weak and strong peaks.
| X-ray Sources | Co-mounted molybdenum and copper Enhance X-ray sources |
|---|---|
| Detector | 135 mm Atlas CCD detector |
| Dynamic Range | 18-bit |
| Goniometer | 4-circle kappa goniometer |
| Sample to Detector Distance | 40-150 mm |
| Unit Cell Resolution | up to 500 A |
| Software | CrysAlis |
It is the ideal X-ray system for today's modern small molecule crystallography laboratory.
The X-ray tube exchange takes only a few minutes and requires minimal or no re-alignment.
