The AOL1426 is a N-Channel Enhancement Mode Field Effect Transistor with excellent RDS(ON), low gate charge. It is suitable for use as a high side switch in SMPS and general purpose applications.
The AOL1426 is an N-Channel Enhancement Mode Field Effect Transistor designed for use as a high side switch in SMPS and general purpose applications. It utilizes advanced trench technology to provide excellent Rds(on) and low gate charge. The device is available in an UltraSO-8 package and is Pb-free, meeting ROHS specifications.
| Drain-Source Voltage | 30 V |
|---|---|
| Continuous Drain Current | 46 A |
| Power Dissipation | 43 W |
| Junction and Storage Temperature Range | -55 to 175 °C |
| On state drain current | 120 A |
| Total Gate Charge | 28 nC |
