This is a Toshiba CompactFlash™ card that is based on flash technology and uses an ATA interface flash memory card. It is constructed with a flash disk controller chip and a NAND-type （Toshiba） flash memory device. The card supports both 5-Volt and 3.3-Volt power supplies. It comes in capacity of 8, 16, 32, 48, 64, 96, 128, 160, 192, 256, 320, 384 and up to 512 MB unformatted for type-I card. It is a perfect choice of solid-state mass-storage cards for battery backup handheld devices such as Digital Camera, Audio Player, PDA, or the applications that require high environment tolerance with high performance sustained write speed.
The THNCFxxxMBA/BAI series is a flash technology-based CompactFlash card utilizing an ATA interface. It is constructed with a flash disk controller chip and Toshiba NAND-type flash memory, supporting both 5-Volt and 3.3-Volt power supplies. The cards are certified in accordance with the CompactFlash Certification Plan and emulate IDE hard disk drives, making them suitable for battery backup handheld devices and applications requiring high performance and environmental tolerance.
| Dimensions (Type I) | 36.4mm(L) x 42.8mm (W) x 3.3mm (H) |
|---|---|
| Storage Capacities | 8 to 512 MB (unformatted) |
| Sustained Write Speed (8MB to 48MB) | 1.5 Mbytes/second |
| Sustained Write Speed (64MB to 512MB) | 3.2 Mbytes/second |
| Sustained Read Speed | 6.5 Mbytes/second |
| Operating Temperature (Commercial) | 0°C to 70°C |
| Operating Temperature (Industrial) | -40°C to 85°C |
The card operates in both 5-Volt and 3.3-Volt power supplies.
Yes, it is substantially compatible with PC Card standard and PC Card ATA.
It supports PIO mode 4 at 16.6 Mbytes/second theoretically.
