FS5VS-18A is a high-voltage power MOSFET manufactured by Mitsubishi Electric. Its maximum voltage is 900V and its maximum current is 5A. The rated current is 1.5A. The device is packaged in a TO-220 package and is suitable for applications such as SMPS, DC-DC converters, battery chargers, printers, copiers, HDDs, FDDs, TV, VCRs, and personal computers.
This document is a technical datasheet for the Mitsubishi FS5VS-18A Nch Power MOSFET. It provides maximum ratings including drain-source voltage of 900V and drain current of 5A. The device is designed for high-speed switching use in applications such as SMPS, DC-DC converters, battery chargers, and power supplies for printers and computers.
| Drain-source voltage (VDS) | 900 ± 30 V |
|---|---|
| Maximum power dissipation (PD) | 125 W |
It is designed for high-speed switching use in SMPS, DC-DC converters, battery chargers, and power supplies for printers, copiers, HDDs, FDDs, TVs, VCRs, and personal computers.
The maximum drain-source breakdown voltage (V(BR)DSS) is 900 ± 30 V.
