CYPRESS CY28RS400 Clock Generator for ATI RS400 Chipset handbook

Update: 30 September, 2023

The CY28RS400 is a clock generator for ATI® RS400 chipsets from Cypress Semiconductor Corporation. It supports Intel® CPUs, selectable CPU frequencies, differential CPU clock pairs, 100MHz differential SRC clocks, 48MHz USB clock and 33MHz PCI clock. It also has a low-voltage frequency select input, I2C support, ideal Lexmark Spread Spectrum profile and a 3.3V power supply.

---

File format: PDF

Size: -

MD5 Checksum: 9C8F31904420603121CBC4DD7D305B7D

Publication date: 06 June, 2012

Downloads: -

PDF Link: CYPRESS CY28RS400 Clock Generator for ATI RS400 Chipset handbook PDF
