The document provides information on the features and characteristics of Mini-Circuits products, including conversion loss, frequency range, and connector types.
The Mini‑Circuits Level 10 series provides broadband frequency mixers covering 50 kHz to 8 GHz. Each mixer supports up to +10 dBm LO power and up to +5 dBm RF input, with typical conversion loss in the low‑single‑digit dB range and high LO‑RF and LO‑IF isolation.
The sheet lists the available models (TFM‑15, TFM‑150, TUF‑1LH, etc.), their frequency ranges, conversion‑loss figures, isolation values, connector options (BNC or SMA), and case styles. Ordering information, pricing, and quality‑control notes are also included.
| Frequency range | 50 kHz – 8 GHz |
|---|---|
| LO power limit | +10 dBm |
| RF power limit | +5 dBm |
The mixers can handle up to +10 dBm LO power.
When ordering, specify either BNC or SMA connectors.
