BAΟΟST / BAΟΟSFP series Regulator ICs are low drop-out type voltage regulators with an ON/OFF switch from Toshiba. They feature built-in overvoltage protection, overcurrent protection and thermal shutdown circuit. These regulators are available in TO220FP-5 and TO252-5 standard packages.
The BAOOST and BAOOSFP series are low‑dropout voltage regulator ICs that include an ON/OFF switch. They are intended to provide a stabilized output voltage from a fluctuating DC input and are available in fixed output versions of 3.3 V, 5 V, 6 V, 7 V, 8 V, 9 V, 10 V and 12 V, each capable of delivering up to 1 A.
The devices incorporate built‑in over‑voltage, over‑current and thermal‑shutdown protection, and are offered in standard TO‑220FP‑5 and TO‑252‑5 packages. Detailed electrical characteristics, pin descriptions, recommended operating conditions, and measurement circuits are provided for designers.
| Fixed output voltages | 3.3 V, 5 V, 6 V, 7 V, 8 V, 9 V, 10 V, 12 V |
|---|---|
| Maximum output current | 1 A |
| Maximum power‑supply voltage (Veo) | 35 V |
| Operating temperature range | -40 °C to +85 °C |
| Storage temperature range | -55 °C to +150 °C |
They include built‑in over‑voltage protection, over‑current protection, and a thermal shutdown circuit.
