This document is the specification of AC/DC converter
This manual presents the block diagram of the ROHM 141V AC/DC converter. The device converts a 100 V DC input to a 141 V output using a switching regulator based on a chopper topology, with internal point A switching between 0 V and 141 V and the output smoothed by a capacitor.
The document also includes application notes, stating that the converter is intended for ordinary electronic equipment and that use in high‑reliability devices such as medical instruments requires prior consultation with ROHM sales. Reproduction of the technical content is prohibited without ROHM's permission. This manual is written in Chinese.
| Input voltage | 100 V DC |
|---|---|
| Output voltage | 141 V |
| Model | 141V |
| Coil type | Built‑in or external coil |
| Coil type (alternative) | External coil only |
The converter requires a 100 V DC input.
It provides a regulated 141 V output.
