This document is the installation guide for AXIS 262+ Network Video Recorder, providing instructions for installing the AXIS 262+ Network Video Recorder on your network. For all other aspects of using the product, please see the User’s Manual.
This installation guide explains how to set up the Axis 262+ network video recorder, including the items supplied in the package and the basic hardware layout of the front and rear panels. It also points to the User’s Manual for additional configuration details.
The guide covers connecting the recorder to the network, powering the unit, configuring an IP address (via AXIS IP Utility, manual ARP/Ping, or DHCP), setting the root password, and accessing the device locally or from the Internet. It includes notes on required cables, indicator LEDs, and optional external I/O devices.
| Power supply voltage | 12 V DC |
|---|---|
| Default IP address | 192.168.0.90 |
| Front panel indicators | Disk, Power, Network, Status |
| Rear panel connectors | 9‑pin I/O terminal, RS‑232, Network connector |
You can assign an IP address using the free AXIS IP Utility, manually via ARP/Ping commands, or let a DHCP server assign one.
The default administrator username is "root"; you must set a password the first time you access the device.
The package contains the AXIS 262+ recorder, a 12 V DC power supply with cables, a CD with software and documentation, and printed materials such as this installation guide and the warranty document.
Configure your router to forward the appropriate port to the recorder’s IP address and refer to the NAT traversal section of the User’s Manual for details.
