This document is the technical information for the S3G/S3G D B-342 type relay
This service manual covers the Omron G6L solid‑state relay family, including the G3S and G3SD series. It describes the electrical characteristics, input voltage options (DC5 V, DC12 V, DC24 V) and output ratings (AC100‑240 V, up to 1 A load current), as well as insulation resistance and environmental limits.
Installation notes address concentrated mounting, required heatsinks, and the use of silicone thermal grease. Common precautions, mechanical dimensions, and performance data such as response time and leakage current are also provided to aid technicians in maintenance and repair. This manual is written in Chinese.
| Input voltage | DC5 V, DC12 V, DC24 V |
|---|---|
| Insulation resistance | ≥ 100 MΩ |
| Operating temperature range | -30 °C ~ +80 °C |
The relay can be powered with DC5 V, DC12 V, or DC24 V.
It can operate from –30 °C to +80 °C.
Use a heatsink and apply silicone thermal grease as described in the installation section.
