The 66510 series low‑voltage lampholders are offered in red, amber, green, clear and blue lenses and can be supplied for 6 V, 12 V or 24 V as specified. These lampholders are not suitable for mains voltage and feature polished chrome‑finished brass bodies.
Dimensions and construction details include various panel‑type bodies (E10, B9) with brass or nylon materials, compatible panel thickness up to 14.2 mm (or 6.2 mm for certain types), and an optional rubber washer that provides an IP66 sealing rating.
| Voltage options | 6 V, 12 V, 24 V |
|---|---|
| Lens colors | Red, Amber, Green, Clear, Blue |
| Maximum panel thickness | up to 14.2 mm (some versions) |
| Body material | Polished chrome‑finished brass |
They can be supplied for 6 V, 12 V, or 24 V as specified.
Red, Amber, Green, Clear, and Blue lenses are offered.
No, they are not suitable for mains voltage.
