FRONT-MSTB 2,5/ 6-STF-5,08 is a connector produced by PHOENIX CONTACT GmbH & Co. KG. Its rated current is 12 A, the rated voltage is 250 V, the pitch is 5.08 mm, the number of positions is 6, the connection type is screw connection, and the color is green.
The FRONT-MSTB 2,5/6-STF-5,08 is a screw‑connection terminal block with a 5.08 mm pitch, six positions and a green colour housing. It is rated for a nominal current of 12 A and nominal voltages of 250 V (or 320 V for certain versions), and complies with EN‑VDE standards.
The product line includes various accessories such as removal aids, marker cards, and a specialized screwdriver. Certifications include CB, CSA, CUL, GL, GOST, UL and VDE‑PZI, and the unit is RoHS‑compliant. Technical drawings and mounting options for DIN‑rail installation are provided.
| Nominal current | 12 A |
|---|---|
| Nominal voltage | 250 V |
| Pitch | 5.08 mm |
| Number of positions | 6 |
| Connection type | Screw connection |
| Mounting type | DIN rail |
| Color | green |
| Weight per piece | 0.01905 kg |
The terminal block is rated for a nominal current of 12 A.
The pitch is 5.08 mm.
It carries CB, CSA, CUL, GL, GOST, UL and VDE‑PZI certifications.
