LUMBERG Klinkensteckverbinder nach JISC 6560 2 5 mm Jack connectors according to JISC 6560 2.5 mm Connecteurs jack suivant JISC 6560 2 5 mm handbook(2)

About this manual

The KLB 13 is a 3‑pole (stereo) 2.5 mm jack connector compliant with JISC 6560. It is a straight version with kink protection and solder terminals, suitable for both male and female mating.

Key specifications include a temperature range of -20 °C to +70 °C, a POM body, CuZn contacts nickel‑plated, PE housing, rated current 0.5 A, rated voltage 34 V AC/DC, test voltage 500 V for 60 s, and insulation resistance of 10⁸ Ω. This manual is written in German.

What's inside

• Temperature range
• Materials
• Mechanical data
• Electrical data
• Compliance (JISC 6560)
• Ordering information

Specifications

Frequently asked questions

What is the operating temperature range of the KLB 13 jack connector?

It operates from -20 °C to +70 °C.

What materials are used for the body and contacts?

The body is made of POM and the contacts are CuZn with a nickel plating.

What are the electrical ratings for current and voltage?

The connector is rated for 0.5 A current and 34 V AC/DC voltage.

What test voltage and insulation resistance are specified?

A test voltage of 500 V for 60 seconds and an insulation resistance of 10⁸ Ω are specified.
