NEB21R is a power supply connector from Lumberg, with a rated voltage of 12V and a plug-pull life of ≥5000 times
The leaflet describes the NES/J 21 series power‑supply connectors for printed‑circuit‑board mounting. It lists the temperature operating range, material grades, and mechanical dimensions such as opening and pin diameters, insertion and withdrawal forces.
Electrical data include contact resistance, nominal current and voltage, test voltage, and insulation resistance. Ordering information and minimum order quantities are also given. This manual is written in German.
| Operating temperature range | -20 °C to +70 °C |
|---|---|
| Body material | PC, V2 according to UL 94 |
| Contact pin material | CuZn, nickeled |
| Test voltage | 500 V for 60 s |
It operates from -20 °C to +70 °C.
