This is an instruction manual for Mini Modular Terminals TS 15 / PA
The Weidmuller Mini Modular Terminals family includes a range of modular PE, fuse, push‑on, solder and wire‑wrap terminals. Each variant is designed for use in hazardous ATEX areas and complies with IEC 60947‑7‑1, IEC 60947‑7‑2 and EN 50019 standards.
The leaflet provides detailed dimensions, rated voltage and current values, clamping ranges, torque specifications and ordering numbers for all terminal types, as well as accessories such as cross‑connection blocks, end plates and labeling tags.
| Rated voltage (to adjacent terminal for PE) | 250 V |
|---|---|
| Rated current | 175 A (max for some variants) |
| Maximum conductor cross‑section | 24 mm² |
| Dimensions (TS 15 mm terminal) | 5.1 × 24.8 × 25 mm (W × L × H) |
The terminals are rated for 250 V (to adjacent terminal for PE) according to the data sheet.
The maximum rated current is up to 175 A for the higher‑current variants.
The TS 15 mm terminal measures 5.1 mm wide, 24.8 mm long and 25 mm high.
