This product is a PC terminal block from PHOENIX CONTACT. It has a nominal current of 13.5A and a rated voltage of 250V. The pitch between the terminals is 5.08mm. It has 10 connection points and the connection method is screw connection. It can be used for soldering. The conductor/PCB connection direction is 55°. The color is green.
The SMKDSN 1,5/10-5,08 is a 10‑position screw‑connection terminal block with a 5.08 mm pitch, designed for mounting on printed circuit boards. It is rated for 13.5 A nominal current and 250 V nominal voltage, making it suitable for a variety of industrial wiring applications.
The document lists detailed technical data such as dimensions, tightening torque, surge voltage ratings, and approved certifications. It also includes commercial information, accessories, and ordering details for the product.
| Nominal current | 13.5 A |
|---|---|
| Nominal voltage | 250 V |
| Pitch | 5.08 mm |
| Number of positions | 10 |
| Length | 12 mm |
| Weight per piece | 0.01119 kg |
The nominal current rating is 13.5 A.
It has 10 positions.
The pitch is 5.08 mm.
Each piece weighs 0.01119 kg.
