This document provides detailed information about KLS 40 3.5mm 3-pole/stereo straight jack connector, including product specifications, parameters, characteristics, etc.
The JISC 6560 3.5 mm jack connector from Lumberg is a 3‑pole stereo PCB‑mount socket with a break contact. It is designed for operation from –20 °C to +70 °C and is built from UL‑94‑rated PPO/VO body material and a POM, HB cover. The contacts are made of copper alloy and are silver‑tinned.
Mechanical data include an insertion force of 5–30 N, withdrawal force of 5–30 N and a rated life of 5 000 mating cycles. Electrical characteristics are a contact resistance below 30 mΩ, a rated current of 1 A, a rated voltage of 34 VAC/DC, a test voltage of 500 V AC/60 Hz and an insulation resistance of 10⁹ Ω. The socket mates with standard jack plugs such as 1532‑01, KLS‑40, KLS‑44 and KLS‑44 V. This manual is written in German.
| Temperature range | -20 °C to +70 °C |
|---|---|
| Body material | PPO, VO (UL 94) |
| Cover material | POM, HB (UL 94) |
| Contact material | Copper alloy, silver‑tinned |
| Insertion force | 5–30 N |
| Withdrawal force | 5–30 N |
| Mating cycles | 5 000 |
| Contact resistance | < 30 mΩ |
| Rated current | 1 A |
| Insulation resistance | 10⁹ Ω |
It can be used from –20 °C up to +70 °C.
The connector is rated for 5 000 mating cycles.
The rated current is 1 A.
An insertion force of 5–30 N is specified.
