This document describes the features and characteristics of MDSM/RTG88 micro miniature connectors, including shielded connectors, doubledecker connectors, contacts, locking devices, straight solder pin connectors, crimp contact connectors for panel mounting, cables, and tools. The connectors are suitable for components in telecommunications and computers that require shielding.
The MDSM/RTG88 is part of Cannon's microminiature shielded connector series, designed for telecom, communications, and computer applications that require robust shielding. The catalog lists various connector configurations, including straight solder pins, crimp contacts, and double‑decker options, with contact counts ranging from 9 to 30.
Technical data includes contact spacing, temperature range, current rating, test voltage, contact resistance, insulation resistance, and shielding effectiveness. The document also contains product safety guidelines, handling instructions, and packaging details for tube‑loaded connectors.
| Solder pin spacing | 1.27 x 2.54 mm |
|---|---|
| Temperature range | -55 °C to 125 °C |
| Current rating | 25 A @ 25 °C |
| Test voltage | 350 V rms |
| Contact resistance (crimp version) | ≤20 mΩ |
| Contact resistance (pcb version) | ≤35 mΩ |
| Insulation resistance | ≥5000 MΩ |
The connector can carry up to 25 A at 25 °C.
