SURE-SEAL connectors are a series of low cost, UL and CSA recognized environmental connectors with a one-piece molded body and rugged multiple moisture seals.
The SURE-SEAL series are low‑cost, UL and CSA recognized environmental connectors designed for harsh automotive and industrial applications. Their one‑piece molded bodies and multiple moisture seals protect against contaminants, vibration, shock, and extreme temperatures.
The datasheet lists key electrical parameters such as contact resistance, insulation resistance, dielectric withstand voltage, and wire‑gauge ranges, as well as safety and handling guidelines for field service and installation.
| Operating temperature range | -40°C to 105°C |
|---|---|
| IP rating | IP66A |
| Contact resistance | 10 milliohms max |
| Insulation resistance | 100 MΩ min |
| Dielectric withstand voltage | 1200 VAC |
| Wire gauge range | 0.5‑1.5 mm (AWG 14‑20) |
| Number of contacts | 1‑10 |
| RoHS compliance | Yes |
They meet the IP66A rating for water submersion.
They are rated for operation from –40 °C up to 105 °C.
The contact resistance is limited to 10 milliohms maximum.
Yes, the connectors are RoHS compliant.
