The document is a product information table for lwd-series power modules, which provides information such as product model, input and output voltage, output current, and maximum output power.
The Lambda LWD series includes compact LED drivers with output powers of 15 W, 30 W and 50 W. They feature a wide universal input voltage range (85 ~ 265 VAC, DC 110 ~ 350 V) and dual isolated outputs available at 5 V, 12 V or 24 V. The low‑profile design is about 1 inch (26 mm) thick and offers a one‑year warranty.
Key specifications such as input‑output withstand voltage (2 kVAC), operating ambient temperature (0 ~ +60 °C), and output derating curves are listed, along with safety approvals (UL1950, CSA1402C, EN60950) and FCC class A EMI compliance. Mounting dimensions and hole patterns are provided for easy integration into equipment.
| Input voltage range | 85 ~ 265 VAC (47 ~ 440 kHz), DC 110 ~ 350 V universal input |
|---|---|
| Output power options | 15 W, 30 W, 50 W |
| Output voltage options | 5 V, 12 V, 24 V |
| Thickness | Approx. 1 inch (26 mm) |
| Withstand voltage | 2 kVAC (input‑output and input‑FG for 1 min) |
| Operating ambient temperature | 0 ~ +60 °C |
| Safety certifications | UL1950, CSA1402C, EN60950 |
| EMI compliance | FCC class A |
| Protection functions | Over‑voltage and over‑current protection |
The series accepts a universal input of 85 ~ 265 VAC (47 ~ 440 kHz) and DC 110 ~ 350 V.
The LWD series is offered in 15 W, 30 W and 50 W output power versions.
Each unit comes with a one‑year warranty.
