The SY10/100E404 are 4-bit differential AND/NAND devices, ideal for pulse shaping applications where duty cycle skew is critical. The differential inputs and outputs allow for their use as fully differential 2-input OR/NOR functions. The output RISE/FALL times of these devices are significantly faster than most other standard ECLinPS devices, resulting in an increased bandwidth. The differential inputs have clamp structures which will force the Q output of a gate in an open input condition to go to a LOW state. Thus, inputs of unused gates can be left open and will not affect the operation of the rest of the device.
The SY10E404 and SY100E404 are 4‑bit differential AND/NAND devices designed for pulse‑shaping applications where duty‑cycle skew is critical. They feature differential operation, internal 75 kΩ pull‑down resistors, high‑frequency outputs, and are fully compatible with Motorola 10E/100E404. The devices are offered in a 28‑pin PLCC package.
The datasheet provides electrical characteristics such as input high current, power‑supply current, input sensitivity, common‑mode range, propagation delays, and rise/fall times, as well as ordering codes for commercial parts. These specifications help designers evaluate the devices for high‑speed logic and differential signaling applications.
| Package | 28‑pin PLCC |
|---|---|
| Common Mode Range (VCMR) | –1.5 V to 0 V |
| Propagation Delay tPHL (Diff) | 475 ps (typ) |
They are available in a 28‑pin PLCC package.
Yes, they are fully compatible with Motorola 10E/100E404.
The typical propagation delay (tPHL) is about 475 ps.
