ACSL-6xx0 is a fully digital logic gate optocoupler, providing full duplex and bidirectional isolated data transfer and communication capability. Available in 8-pin and 16-pin narrow-body SOIC packages and specified over the temperature range of -40°C to +100°C
The ACSL-6xx0 series are high‑speed, bi‑directional optocouplers offering full‑duplex isolated data transfer. They are available in 8‑pin and 16‑pin narrow‑body SOIC packages and operate over a wide supply voltage range of 3.0 V to 5.5 V.
The datasheet details electrical characteristics such as a typical data rate of 15 MBd, common‑mode rejection of 10 kV/µs, and temperature rating from –40 °C to +100 °C. It also includes package dimensions, solder‑reflow profiles, and regulatory compliance information for designers.
| Typical data rate | 15 MBd |
|---|---|
| Supply voltage range | 3.0 V to 5.5 V |
| Operating temperature range | -40 °C to +100 °C |
| Package types | 8‑pin and 16‑pin narrow‑body SOIC |
| Input drive current | 7 mA to 15 mA |
The typical data rate is 15 MBd (with a minimum of 10 MBd).
They operate over a supply voltage range of 3.0 V to 5.5 V.
They are rated from –40 °C to +100 °C.
The series is offered in 8‑pin and 16‑pin narrow‑body SOIC packages.
