The document contains information about several orderable devices, including their models, package types, pin count, package quantity, and other characteristics.
This document provides detailed packaging options for the SN54LS112A device, including the available package types such as CDIP, CFP, and SOIC, along with pin counts and package quantities. It also lists the eco‑plan status, lead/ball finish, moisture sensitivity level (MSL) and peak temperature limits for each package variant.
Additional sections define marketing status values (ACTIVE, LIFEBUY, NRND, etc.), explain the Eco Plan classifications (Pb‑Free, Green), and include legal notices and warranty information from Texas Instruments.
| Package Type | CDIP |
|---|---|
| Pins | J 161 |
| Package Quantity | A42 |
| Eco Plan | TBD |
| Lead/Ball Finish | SNPB |
| Moisture Sensitivity Level (MSL) | TBD |
ACTIVE indicates the product is recommended for new designs.
The Eco Plan is listed as TBD, meaning the Pb‑Free/Green conversion plan has not been defined yet.
