The Samsung SLD63518240 laser diode datasheet provides comprehensive information on the device's optical output power, wavelength, and electrical characteristics. It includes the diode's absolute maximum ratings, typical operating conditions, and built‑in photodiode monitoring features.
The document also covers safety and handling guidelines, such as electrostatic discharge protection, surge current mitigation, and heat‑diffusion requirements. Packaging details, part‑number decoding, and application notes for measuring instruments are included to aid designers and technicians.
| Wavelength | 635 nm |
|---|---|
| Optical output power (CW) | 5 mW |
| Package type | TO‑18 |
| Threshold current | 30 mA |
| Operating voltage | 2.2 V |
| Operating temperature range | -10 °C ~ +40 °C |
| Storage temperature range | -40 °C ~ +85 °C |
Samsung red and infrared laser diodes correspond to Class IIIb of the International Radiation Standard for laser products.
Use an AC noise filter, a slow‑starter circuit, or an appropriate CR filter to limit spike currents during power‑on/off switching.
The diode is supplied in a TO‑18 (10‑18 mm) package.
The typical continuous‑wave optical output power is 5 mW.
