K6T0808C1D Family CMOS SRAM is a low power static random access memory produced by Samsung Electronics. The family supports a wide range of operating temperatures and offers a variety of features, including low power consumption, high performance, high integration, and low cost.
The K6T0808C1D family is a 32K×8‑bit low‑power CMOS static RAM offered by Samsung. It supports a wide supply voltage range (4.5 V – 5.5 V), low data‑retention voltage (2 V min) and three‑state TTL‑compatible outputs. Multiple package options are available, including 28‑DIP, 28‑SOP and thin‑small‑outline (TSOP) formats.
The document lists absolute maximum ratings, recommended DC and AC operating conditions, detailed timing parameters for read and write cycles, and mechanical dimensions for each package type. It also provides a product list covering commercial and industrial temperature grades and their corresponding part numbers.
| Organization | 32Kx8 |
|---|---|
| Power Supply Voltage | 4.5 V – 5.5 V |
| Low Data Retention Voltage | 2 V (min) |
| Package Types | 28‑DIP‑600B, 28‑SOP‑450, 28‑TSOP1‑0813.4 F/R |
| Operating Temperature (Commercial) | 0 °C – 70 °C |
| Operating Temperature (Industrial) | -40 °C – 85 °C |
The device operates from 4.5 V to 5.5 V.
It is offered in 28‑DIP‑600B, 28‑SOP‑450, and 28‑TSOP1‑0813.4 F/R packages.
The industrial grade works from –40 °C to +85 °C.
