Am29SL800D 8 Megabit (1 M x 8-Bit/512 K x 16-Bit) CMOS 1.8 Volt-only Super Low Voltage Flash Memory is a super low voltage flash memory.
The Am29SL800D is an 8‑Mbit, 1.8 V flash memory offered in 48‑pin TSOP and 48‑ball FBGA packages. It supports single‑power‑supply operation, fast access times as low as 90 ns, and a flexible sector architecture for both byte and word modes.
The device includes power‑saving features such as automatic sleep and standby modes, an erase‑cycle guarantee of one million cycles per sector, and a 20‑year data retention rating at 125 °C. Detailed pin configurations, command definitions, and timing diagrams are provided for system integration.
| Memory capacity | 8 Mbit (1 M × 8‑bit / 512 K × 16‑bit) |
|---|---|
| Operating voltage | 1.8 V |
| Access time | 90 ns (fastest) |
| Sleep mode current | 0.2 µA |
| Standby mode current | 0.2 µA |
| Read current | 5 mA |
| Program/erase current | 15 mA |
| Package options | 48‑pin TSOP, 48‑ball FBGA |
| Erase‑cycle guarantee | 1,000,000 cycles per sector |
| Data retention | 20 years at 125 °C |
The device operates from a single 1.8 V power supply for both read and write functions.
Access times are available as fast as 90 ns, with other options at 100, 120, and 150 ns.
The part is offered in a 48‑pin TSOP package and a 48‑ball FBGA package.
The device guarantees a minimum of one million erase cycles per sector.
