This document is about the specifications of the MC1604B series, including general specifications, mechanical data, electrical characteristics, optical characteristics, etc.
This datasheet describes the MC1604B series LCD module manufactured by Everbouquet. It includes general specifications, mechanical data, absolute maximum ratings, electrical and optical characteristics, as well as wiring and power supply information.
The document lists dimensions, character layout, backlight options, viewing angles, contrast ratios and recommended driving voltages, enabling designers to integrate the module into their products with confidence.
| Number of characters per line | 16 |
|---|---|
| Number of lines | 4 |
| Module size (max) | 87.0 mm × 60.0 mm |
| Effective display area | 61.8 mm × 25.2 mm |
| Character size | 2.96 mm × 4.16 mm |
| Dot size | 0.56 mm × 0.56 mm |
| Power supply for logic (Vop‑Vss) | 6.0 V |
| Array LED forward voltage | 5.0 V |
| Array LED typical current | 170 mA |
| Viewing angle (typical) | 20°–30° |
The MC1604B module displays 16 characters per line across 4 lines.
The module’s maximum size is 87.0 mm wide by 60.0 mm high.
The recommended LCD driving voltage is about 4.2 V for TN type and 4.5 V for STN/FSTN types, with a possible ±0.5 V fluctuation.
