HWS1500 Series 1 is a single output industrial power supply with high power density, high efficiency, and wide range AC input. It comes with a 5-year warranty and is suitable for global use. The power supply supports remote on/off and adjustment, and is RoHS compliant. It is widely used in factory automation, test and measurement, broadcast and communications, display systems, and semiconductor manufacturing equipment.
The HWS1500 series offers a universal input range of 85‑265 VAC, high efficiency (>105 %), and a power factor that meets EN61000‑3‑2. It includes remote sense, isolated remote on/off, and a green LED indicator for status monitoring. The series is designed for factory automation, test & measurement, broadcast, and other industrial applications.
Physical dimensions are 280 mm × 126.5 mm × 82 mm (W × H × D) and it operates from –10 °C to +70 °C with storage limits of –30 °C to +85 °C. The unit complies with multiple safety standards, including UL60950‑1, CSA60950‑1, EN60950‑1, EN50178, and CE.
| Input voltage range | 85‑265 VAC |
|---|---|
| Input current (typical) | 1 A |
| Size (W × H × D) | 280 mm × 126.5 mm × 82 mm |
The HWS1500 accepts a universal input voltage of 85 VAC to 265 VAC.
