This document provides an overview of the dimensions, maximum ratings, and optical characteristics of dot matrix LCD modules and character LCD modules. It also includes general specifications for character LCD modules and graphic LCD modules. Additionally, information about backlights for LCD modules and the numbering system is provided.
The leaflet presents Everbouquet's range of character and graphic dot‑matrix LCD modules, including the MC1601H series. It lists dimensional overviews, maximum ratings, optical characteristics, and backlight options for each series, with tables showing size, pin connections, and built‑in controller ICs.
Contact information for Everbouquet/Wayton is provided, along with notes on temperature ranges, power supply options, and availability of touch‑screen versions. The document also outlines the numbering system and checkpoints for custom‑designed LCD modules.
| Operating temperature range (operating) | 0 °C to +50 °C |
|---|---|
| Operating temperature range (storage) | -20 °C to +70 °C |
| Backlight supply voltage | +3 V to +5 V (varies by model) |
| External dimensions (example MC1601H) | L 122.0 mm × W 5.0 mm × H 4.4 mm |
The modules operate from 0 °C to +50 °C and can be stored from -20 °C to +70 °C.
Backlight supply can be either +3 V or +5 V, depending on the specific model.
The MC1601H series has external dimensions of approximately 122 mm length, 5 mm width, and 4.4 mm height.
