The LP M675 Hyper Mini TOPLED® High-optical Power LED (HOP) is a high-power LED product with a compact package and a pure green wavelength of 560 nm. It is suitable for applications such as information displays, optical indicators, fiber coupling, backlighting, and indoor/automotive lighting.
The LP M675 is a high‑optical‑power (HOP) LED with a peak wavelength of 560 nm, delivering a Lambertian viewing angle of 120°. It is supplied in a white SMT package with a clear resin encapsulation, suitable for standard SMT assembly and IR reflow or TTW soldering processes. The component is RoHS‑compliant and ESD‑protected up to 2 kV.
Typical applications include indoor and outdoor displays, backlighting, automotive interior lighting, marker lights, and optical indicators. The datasheet provides ordering information, maximum ratings, electrical characteristics, and wavelength group definitions for precise selection. This manual is written in German.
| Maximum forward current (25 °C) | 40 mA |
|---|---|
| Operating temperature range | -40 °C to +100 °C |
| Storage temperature range | -40 °C to +100 °C |
| Junction temperature limit | +125 °C |
The maximum forward current at 25 °C is 40 mA.
Yes, the device is lead‑free and RoHS compliant.
