This document describes the features and characteristics of low power consumption seven segment displays, including industry standard size and pinout, choice of character size and colors, evenly lighted segments, design flexibility, and suitability for long digit string multiplexing.
The HDSP series are low‑current seven‑segment displays designed for applications that require minimal power consumption. They are offered in a variety of character sizes, colors, and pin configurations, with drive currents as low as 1 mA per segment.
The document provides detailed specifications, part‑number tables, package dimensions, luminous intensity categories, and color bin definitions for the HDSP‑335x, HDSP‑555x, HDSP‑751x, HDSP‑A10x, HDSP‑A80x, HDSP‑A90x, HDSP‑E10x, HDSP‑F10x, HDSP‑G10x, HDSP‑H10x, HDSP‑K12x, K70x, N10x, and N40x series.
