This document introduces the features and characteristics of the HDSP-5082 series LED display tube. The series products adopt industry standard size and pin arrangement, provide AlGaAs red, high efficiency red, yellow and green four colors, uniform light, viewing angle ±50°. In addition, it supports common anode or common cathode, single digit, left or right hand decimal point, ±1. Overflow symbol and other design, can meet the needs of different applications.
The 7.6 mm (0.3 in) and 10.9 mm (0.43 in) LED seven‑segment displays are designed for viewing distances up to 3 m (10 ft) and 5 m (16 ft). They use an industry‑standard size package with 7.62 mm (0.300 in) DIP leads on 2.54 mm (0.100 in) centers and are offered in a variety of colors (AlGaAs Red, HER, Yellow, Green) and configurations (common anode, common cathode, left or right hand decimal point, overflow character).
Key features include high light output, sunlight‑viewable AlGaAs technology, selectable intensity and color bins, and robust absolute maximum ratings (operating temperature –20 °C to +100 °C, storage –55 °C to +100 °C). The document also provides part‑numbering, mechanical options, and detailed electrical characteristics for each series.
| Package size | 7.6 mm (0.3 in) / 10.9 mm (0.43 in) |
|---|---|
| Lead spacing | 7.62 mm (0.300 in) DIP leads on 2.54 mm (0.100 in) centers |
| Storage temperature range | -55 °C to +100 °C |
| Reverse voltage per segment | 3.0 V |
The displays are offered in 7.6 mm (0.3 in) and 10.9 mm (0.43 in) package sizes.
Yes, each device is available as either common anode or common cathode.
Color bins are indicated by numbers or letters on the side of the package; see the Color Categories section for the mapping.
