This document describes the features and characteristics of a series of devices, including AlGaAs material, colors, sizes, and packages. These devices have a black surface and color tinted epoxy, and use industry standard size and pinout. They are available in different character sizes and colors, with evenly lighted segments and a wide viewing angle. They support common anode or common cathode and single or two-digit displays. Excellent for long digit string multiplexing.
The HDSP-HX11/HDSP-HX13 series are black‑surface seven‑segment displays offered in 7.6 mm, 10 mm and 14.2 mm sizes. They are available in AlGaAs Red, High‑Efficiency Red, Green and Orange colors, with either common‑anode or common‑cathode configurations.
The datasheet provides detailed electrical and optical characteristics such as luminous intensity, forward voltage, peak wavelength and temperature coefficients, as well as mechanical dimensions, part‑numbering conventions and binning information for intensity and color categories. This manual is written in Chinese.
| Luminous Intensity (typ) per segment | 600 µcd |
|---|---|
| Forward Voltage (typ) per segment | 2.0 V |
| Peak Wavelength | 645 nm |
| Operating Temperature Range | -20 to +100 °C |
The series is available in 7.6 mm, 10 mm and 14.2 mm single‑digit or two‑digit packages.
Available colors are AlGaAs Red, High‑Efficiency Red (HER), Green and Orange.
Each device can be ordered as either common‑anode or common‑cathode.
