The T510 series of solid tantalum capacitors have the characteristics of ultra-low ESR, high capacitance and high reliability.
The T510 series from KEMET provides high‑capacitance, low‑ESR solid tantalum chip capacitors. Key features include ultra‑low ESR (<30 mΩ, <18 mΩ for the E/7260 case), up to 5 A ripple current, and operation from –55 °C to +125 °C. Various voltage ratings and tolerance options (±10 % K, ±20 % M) are available.
Capacitors are supplied in tape‑and‑reel formats compatible with standard EIA‑481‑1 pick‑and‑place equipment. Detailed dimensions, embossing specifications, and performance notes are provided to aid automated handling and reliable assembly.
| ESR (general) | < 30 mΩ |
|---|---|
| ESR (E/7260 case) | < 18 mΩ |
| Ripple current | Up to 5 A |
| Operating temperature range | -55 °C to +125 °C |
| Voltage rating (example) | 25 V at +85 °C (17 V at 125 °C) |
| Capacitance tolerance | ±10 % (K) or ±20 % (M) |
The ESR is less than 30 mΩ generally, and less than 18 mΩ for the new E/7260 case.
They operate from –55 °C up to +125 °C.
