This page contains the specifications for the KEMET 0805 C Series Ceramic Capacitors, including capacitance, rated voltage, external dimensions, tolerances, package and mounting type
The KEMET C0805C103K5RAC is a standard‑size ceramic chip capacitor offered in a variety of dielectric types (C0G, X7R, Z5U, Y5V) and voltage ratings up to 50 V (suitable for 63 V applications). The datasheet provides the capacitance coding, tolerance codes, and temperature‑characteristic designations for precise selection.
Key mechanical data are given for the 0805 package: length 1.0 mm, width 0.5 mm, thickness 0.55 mm, with recommended mounting methods such as solder reflow and wave. Packaging options include tape‑and‑reel per EIA‑481‑1 and bulk‑cassette for 0402, 0603, and 0805 sizes.
| Capacitance coding | First two digits are significant figures, third digit is number of zeros (pF) |
|---|---|
| Tolerance code B | ±0.10 pF |
| Dielectric options | C0G (NP0), X7R, Z5U, Y5V |
| Maximum voltage rating | 50 V (usable up to 63 V) |
| Temperature coefficient G | C0G (NP0) ±30 ppm/°C |
| Failure rate level | A – Not Applicable |
| Mounting method example | Solder Reflow |
The capacitor is offered with C0G (NP0), X7R, Z5U and Y5V dielectrics.
It is rated for 50 V, and can be used in applications up to 63 V.
Tolerance code B corresponds to a tolerance of ±0.10 pF.
