ILL3A003 is a 4 watt LED module light source from CML, with 11 or 24 degree beam and 50,000 hours life span. The product is available in red, amber, green, cyan, blue, warm white and cool white colors.
The 4 Watt LED Module from CML Innovative Technologies is a compact 1.38" (85 mm) round light source using high‑power 1 W LEDs. It is offered in seven colors – Cool White, Warm White, Blue, Cyan, Green, Amber and Red – and is suited for spot, landscape, architectural, portable, task, track, point‑of‑purchase, cabinet and display case lighting.
Key specifications include an operating life of 50,000 hours, recommended PCB temperature of 65 °C (max 100 °C), thermal resistance of 31 °C/W, and selectable optics with 11° or 24° beam angles. The module draws 350 mA at 3.8 W and uses 8" power leads. Photometric data and radiation patterns are provided for both optic options.
| Operating Life | 50,000 hours |
|---|---|
| Recommended PCB Temperature | 65 °C |
| Maximum PCB Temperature | 100 °C |
| Thermal Resistance (Rthj‑a) | 31 °C/W |
| Beam Angle | 11° or 24° |
| Power Leads Length | 8 inches |
The module is rated for 50,000 hours of operation.
The recommended operating PCB temperature is 65 °C.
It is available in Cool White, Warm White, Blue, Cyan, Green, Amber, and Red.
The module offers optics with either an 11° or a 24° beam angle.
