This product is CML's ILL2A0005 model 8 watt LED strip. The product consumes 8 watts and uses 6 high power light emitting diodes (1 watt LEDs) as light sources. The product supports seven colors: red, orange, yellow, green, cyan, blue, and white. The product is 302mm long and 13mm wide and can be used for decorative lighting, cabinet lighting, and display case lighting.
The CML 8 Watt LED Strip is a high‑power LED lighting solution designed for decorative edge, cove, architectural and task lighting applications. It uses 1 W LEDs on a metal‑clad PCB and offers a range of colors including cool white, warm white, blue, cyan, green, amber and red.
Key operating specifications include a recommended PCB temperature of 65 °C, a maximum of 100 °C, thermal resistance of 8.4 °C/W and a projected life of 50,000 hours with 70 % lumen maintenance at the recommended temperature. Photometric data and radiation patterns are provided for various regions.
| Operating PCB temperature (recommended) | 65 °C |
|---|---|
| Maximum PCB temperature | 100 °C |
| Thermal Resistance (Rthj‑a) | 8.4 °C/W |
| Projected life | 50,000 hours |
| LED color – Cool White | 6400 K |
The LED strip is rated for a projected life of 50,000 hours with 70 % lumen maintenance at 65 °C.
The recommended operating PCB temperature is 65 °C.
The maximum PCB temperature is 100 °C.
The thermal resistance (Rthj‑a) is 8.4 °C/W.
