LW T773 Hyper TOPLED® RG Hyper-Bright LED is a white light emitting diode produced by Philips company. It features an extremely wide emission angle, making it ideal for backlighting.
The LW 1773 is a hyper‑bright, lead‑free LED with an extremely wide viewing angle, ideal for backlighting and interior automotive lighting. It features a white SMT package with a colored diffused resin, InGaN technology, and a typical color temperature of 5600 K.
The document lists detailed electrical ratings (forward current 20 mA, reverse voltage 76 V, power consumption 80 mW), thermal limits (operating temperature –40 °C to +100 °C, junction max +110 °C), and mechanical data such as package dimensions and tape width. Ordering codes, brightness groups, and compliance information (RoHS, ESD up to 2 kV) are also provided. This manual is written in German.
| Color coordinates (x, y) | x = 0.33, y = 0.33 |
|---|---|
| Typical color temperature | 5600 K |
| Color reproduction index (CRI) | 80 |
| Viewing angle | 120° (Lambertian) |
| Technology | InGaN |
| Optical efficiency | 6 Im/V |
| Operating temperature range | -40 °C to +100 °C |
| ESD withstand voltage | up to 2 kV |
The typical color temperature is 5600 K.
It has a Lambertian viewing angle of 120°.
IR reflow soldering is recommended and the device is suitable for all SMT assembly techniques.
