Power TOPLED® Enhanced thin film LED is a LED lighting product launched by Texas Instruments. The product uses a white P-LCC-4 package and transparent colorless resin.
The Power TOPLED® enhanced thin‑film LED family from OSRAM is offered in five colour variants (super‑red, red, amber, orange and yellow) with peak wavelengths from 590 nm to 633 nm. The devices use an InGaAIP technology and are supplied in a white P‑LCC‑4 package with a colourless clear resin.
Typical performance includes high optical efficiency (up to 69 Im/W), a Lambertian viewing angle of 120°, forward voltage between 1.90 V and 2.65 V (typical) and a maximum forward current of 70 mA. The LEDs are RoHS‑compliant, lead‑free and rated for operation from –40 °C to +100 °C.
| Peak wavelength (super‑red) | 633 nm |
|---|---|
| Optical efficiency (super‑red) | 38 Im/W |
| Viewing angle | 120° (Lambertian) |
| Technology | InGaAIP |
| Maximum forward current | 70 mA (25 °C) |
| Operating temperature range | -40 °C to +100 °C |
| Storage temperature range | -40 °C to +100 °C |
| Junction temperature limit | +125 °C |
| ESD withstand voltage | 2 kV |
The LED is offered in super‑red (633 nm), red (625 nm), amber (617 nm), orange (606 nm) and yellow (590 nm).
The super‑red version provides an optical efficiency of 38 Im/W.
The device can be driven up to 70 mA at 25 °C.
It operates from –40 °C up to +100 °C.
