This document describes the features and characteristics of LR W5SM, LA W5SM, LY W5SM Golden DRAGON® Enhanced thin film LED Lead (Pb) Free Product - RoHS Compliant, including its Gehäusetyp, Typischer Lichtfluss, Besonderheit des Bauteils, Wellenlänge, Abstrahlwinkel, Technologie, optischer Wirkungsgrad, etc.
The OSRAM W5SM series comprises three colour variants – red (LR), amber (LA) and yellow (LY) – in a white SMD package with a clear silicone resin. The LEDs are thin‑film InGaAlP devices offering high luminous efficiency in a compact form factor.
The document provides ordering information, maximum ratings, electrical and optical characteristics, wavelength and brightness group definitions, as well as safety and packaging notes. It is intended for designers and distributors needing detailed specifications for integration into traffic signaling, automotive lighting, backlighting and decorative applications. This manual is written in German.
| Typical forward voltage | 2.2 V |
|---|---|
| Forward current (continuous) | 500 mA |
| Optical efficiency (typical, red) | 60 lm/W |
| Viewing angle | 120° |
| ESD withstand voltage | 2 kV |
The continuous forward current rating is 500 mA.
Typical luminous flux is 49 lm (red), 70 lm (amber) and 41 lm (yellow) at 500 mA.
IR reflow soldering is the recommended method.
The LEDs are ESD‑safe up to 2 kV.
