This document is the product specification of Wanda Optoelectronics Technology Co., Ltd. It describes the features and characteristics of the HT-190F-5RB-001N-28R-300FH model, a five-wire analog touch panel.
The document provides the complete technical specifications for the Wanda HT-190F-5RB-001N-28R-300FH five‑wire analog resistive touch panel. It includes dimensions, viewable and active areas, thickness, and detailed electrical, optical, mechanical, environmental and reliability data.
Installation notes describe mounting clearances, gasket placement, grounding requirements, and handling precautions. The sheet also lists warranty terms, inspection methods, and a comprehensive appearance specification for quality control. This manual is written in Chinese.
| Frame Size | 393.40±0.30 mm × 316.65±0.30 mm |
|---|---|
| View Area | 380.90±0.20 mm × 305.65±0.20 mm |
| Active Area | 377.30±0.20 mm × 302.05±0.20 mm |
| Linearity X | ≤1.0 % |
| Chattering (Response Time) | ≤15 ms |
| Insulation Resistance | ≥20 MΩ @ 25 V DC |
| Endurance Voltage | DC 50 V for 60 s without damage |
| Static Load | 500 g over 10 cm² for 30 s |
| Bending | 135° ten times left & right |
| Warranty Period | 2 years limited |
HIGGSTEC offers a limited 2‑year warranty on all five‑wire analog products.
