LCW W5AM Golden DRAGON Plus is a high-efficiency white light LED lighting product from Ledvance. The product uses a white SMD package and a transparent silicone lens. The typical luminous flux is 85 lm@350mA and the maximum is 203 lm@1A. The color temperature range is 2500 K to 4800 K, and the color rendering index is 80. The product has a 170° beam angle and is equipped with ThinGaN technology. It has a luminous efficiency of 102 lm/W.
The LCW W5AM is a lead‑free, RoHS‑compliant LED module with a thin‑GaN technology. It offers high luminous flux (85 Im at 350 mA up to 203 Im at 1 A), a wide color temperature range (2500 K‑4800 K), and a 170° viewing angle, making it suitable for room, architectural, and specialty lighting applications.
The document lists detailed electrical ratings (operating temperature –40 °C to +125 °C, junction temperature up to 135 °C, forward voltage 3.2‑3.7 V, ESD withstand up to 8 kV), ordering codes, chromaticity coordinate groups, and safety information including eye‑safety classification and RoHS compliance. Patent numbers and packing instructions are also included.
| Typical Luminous Flux | 85 Im at 350 mA, up to 203 Im at 1 A |
|---|---|
| Color Temperature | 2500 K to 4800 K |
| Viewing Angle | 170° |
| Optical Efficiency | 102 Im/W at 100 mA (3500 K) |
| Forward Voltage (typ) | 3.2 V |
| Forward Voltage (max) | 3.7 V |
| ESD Withstand Voltage | up to 8 kV |
The LCW W5AM delivers about 85 Im at 350 mA.
Yes, the LCW W5AM is a lead‑free, RoHS‑compliant LED product.
