This file is the drawing of FUTEK LLB500
This data sheet describes the physical dimensions of the support outer ring sensor, including nominal diameters and mounting hole sizes. It also lists the wiring colour code for excitation, signal and ground connections.
Installation notes stress that no load should be applied to the cover and the sensor label must not be touched. The sheet includes a brief wiring diagram and reference numbers for ordering replacement parts.
| Support Outer Ring Diameter | Ø0.15 (nom. Ø0.19) |
|---|---|
| Output Compression | 1.20 |
| Excitation Wire Color | Red |
| Signal Wire Color | Green |
No, do not apply load on the cover.
The excitation wire is red.
