This document is a wiring diagram for FUTEK model LLB300, providing the wiring code and important instructions for the product.
This data sheet presents the key technical details for the FUTEK LLB300 pressure sensor, including wiring code, dimensional tolerances, loading surface specifications, and cable strain‑relief dimensions. It is intended for engineers and technicians who need precise installation and integration information.
The document lists the wiring code (WC1), nominal diameters, loading surface dimensions, and strain‑relief measurements, along with notes on proper handling of the sensor housing and contacts. All information is provided for exclusive use by the original addressee.
| Wiring code | WC1 |
|---|---|
| Nominal diameter | Ø0.08 [Ø2.0] nom. |
| Loading surface diameter | Ø0.74 |
| Strain relief dimension | 0.10 [2.5] |
The wiring code is WC1.
The nominal diameter is Ø0.08 mm (Ø2.0 mm nominal).
The loading surface has a diameter of Ø0.74 mm.
