This is a manual for the control system of an injection molding machine, which introduces the configuration, installation, debugging, and setting of the system.
The PORCHESON BK118 User Manual provides detailed guidance for installing, configuring, and operating the injection molding machine control system. It includes system configuration, wiring diagrams, safety door wiring, and parameter setting instructions.
The manual also contains production management features, input/output inspection, and reference appendices such as dimension drawings and interference suppression methods, helping technicians ensure reliable and safe operation.
| Display size (BK118 back panel) | 5.7" 320×240 |
|---|---|
| Power pack options | PV600 600W, PVB00 300W |
| Standard D/A output current | max. 3 A |
When the safety doors are opened or closed incorrectly, the system issues an alarm after 2 seconds and stops all outputs; proper wiring of LS1‑LS4 signals is required.
Separate high‑pressure and low‑pressure lines from the computer control lines, keep AC connectors and transformers apart, and use the provided shielding wires.
After connecting the DC power supply to the power pack, power on the system and measure the voltage to ensure it matches the nominal value, then check the power pack indicator.
