The document describes the features and characteristics of HCPL-2400 and HCPL-2430 high CMR logic gate optocouplers, including high speed data rate, high common mode rejection, compatibility with various logic families, totem pole and tri-state output, safety certifications, etc.
The Agilent HCPL-2400 and HCPL-2430 are high‑speed optocouplers that combine an 820 nm AlGaAs LED with a fast photodetector, providing up to 40 MBd data rates and high common‑mode rejection. They are compatible with TTL, STTL, LSTTL and HCMOS logic families and feature totem‑pole or three‑state outputs that eliminate the need for external pull‑up resistors.
The document includes electrical specifications, absolute maximum ratings, package dimensions, thermal reflow profile, safety approvals, and recommended application circuits. It also provides ordering information, option codes, and regulatory compliance details for both DIP and surface‑mount versions.
| Typical Data Rate | 40 MBd |
|---|---|
| Supply Voltage | 4.75 V – 5.25 V |
| Output Collector Current | ±25 mA |
| Propagation Delay (typ.) | 55 ns |
| Output Power | 600 mW |
| Input Current | 230 mA |
The optocouplers achieve a typical data rate of 40 MBd.
The recommended supply voltage is between 4.75 V and 5.25 V.
Typical propagation delay is 55 ns.
