This data sheet provides detailed information about the M68HC08QY/QT family of microcontrollers, including product features, specifications, and instruction set.
The MC68HLC908 family datasheet gives a comprehensive overview of the 8‑bit microcontroller architecture, including block diagrams, pin assignments, and functional descriptions of key modules such as the ADC, Auto Wakeup (AWU), Configuration (CONFIG), and Computer Operating Properly (COP) units. It also details the memory organization, including RAM, FLASH, and reserved areas, and explains low‑power modes and interrupt handling.
Additional sections cover electrical characteristics, timing parameters, package dimensions, and ordering information. The document includes revision history, legal notices, and contact details for Freescale Semiconductor worldwide.
The product incorporates SuperFlash® technology licensed from SST.
The most up‑to‑date version is available on Freescale’s website at http://freescale.com.
The datasheet is copyrighted in 2004 by Freescale Semiconductor, Inc.
